KEBV Dismantling Joints provide greater flexibility for the installation and removal of flanged pipework and fittings, or flanged equipments such as valves, meters and pumps. The dismantling joints compensate for axial displacement of the pipe, applicable for water and waste water, temperature range: -10C to 70C
Technical
Specifications of Dismantling Joints
Size
Range
Pressure
Range
PN6,
PN10, PN16, PN25, Class 150 etc.
DN25~DN4500
Design Feature
Compensates
for axial displacement of the pipe during installation;
Standard
compensation ±50 mm;
Mild
steel with spraying painting;
Studs,
nuts of zinc plated , optionally with studs, nuts and tie-rods of stainless
steel。
Body Material
Mild steel Q235A
Bolting and Nut
Steel (zinc plated)
Gaskets
Rubber NBR
Applicable Standards
Flange standard: EN1092-1 or ANSI B16.5
Applications
water, waste water
